USB2.0 interface TX800 double head inkjet printer system,for tape
guide printer
Quick Details:
This program provides various nozzle arrangements and spot color
settings, such as staggered (arranged) full color, white color at
the same time, side by side, side by side full color, side by side
white color, side by side 8 colors (kcmy + 4 spot colors), etc.,
special printing actions Personalized customization is available,
and the feathering mode provides inter-jet feathering (uniform
feathering) mode.
USB2.0 optical fiber inkjet printing control system, application
nozzle model: TX800 |
Data interface: The 1.25G optical fiber is connected to the spray
car board, and the USB2.0 cable is connected to the computer |
Color channel: 6 channels/6 colors |
Nozzle features: Can print water-based, thermal transfer, paint,
eco-solvent, UV and other inks |
Nozzle protection: Nozzle reverse connection protection,
stimulating nozzle (flash spray), short circuit protection |
Board support: Single head, double head, three head, four head,
eight head, sixteen head, thirty-two head |
RIP-software: Mainstream RIP software such as Mengtai, Photoprint,
Rui Cai, ONYX, Wasatch, etc |
Function support: Anti-collision and continuous printing, automatic
height measurement, variable point printing, device power failure
and continuous printing, USB automatic reset, USB disconnection and
continuous printing, paper out detection, ink stack self-check, etc |
Application machine:
Photo machine, UV flatbed machine, white ink scald transfer
machine, double-station direct printing machine, etc.
The Photo machine prints the colorful patterns on the special
materials with the printheads. It is generally used in advertising,
graphics, and CAD industries. It has high precision and long life
of the printhead. The photo machine solves the shortcomings of gray
color and high machine purchase cost, And it can make a variety of
inks for users, such as indoor and outdoor, widely used in many
industries.
UV printing is a high-tech, plate-free, full-color digital
printing. It is not limited by materials. It can be used on metal,
plastic, sliding doors, sliding doors, glass, plates, various
signs, crystal, PVC, acrylic, stone, leather, etc. Color
photo-level printing on the surface. There is no need to make a
plate and complete the printing at one time, with beautiful and
rich colors, abrasion resistance, UV protection, simple and
convenient operation, fast printing image speed, and fully conform
to industrial printing standards.
Application scenario:
Clothing color printing Glass printing PCB legend printing
Product pictures:
Inkjet Printher Control Board TX800 suite
Main board
Head board
About us:
We provide ink-jet board for advertising photo printing, UV board
roll, textile printing and other industries.
Our products cover all kinds of industrial inkjet printer circuit
boards and technical services.
Notes:
1. The warranty period of the board card is 1 year, and the damage
of the board card caused by operation error and human factors is
not covered by the warranty.
2,After acceptance by customers, if there is any doubt, they should
notify our company within 3 days, otherwise it is regarded as
qualified for acceptance.
3. Party B shall cooperate with Party A in technical guidance and
product maintenance. Party A shall keep confidential product
information, materials and manuals of Party B, and both parties
shall be obligated to keep confidential business cooperation
information of both parties.
4. If the Board have after-sales problems, the return freight shall
be borne by the customer.
Packaging and logistics:
Inner Package : bubble plastic bag.
Outter package : Carton.
⇒
⇒
⇒
⇒
